WREN's LA25100 Hydraulic Herculean Puller is made from High Strength Alloy Steel. Two acting hydraulic design controlled by remote hand switch. This puller is used for dismounting bearings, couplings, spindle sleeves and other large sized parts.
CONTACT US
Made of alloy steel with super-high strength; double-acting hydraulic design. Used for dismantling large shafts and perforating work pieces.
LA Series Selection Table
| Type | LA25100 | LA2560 |
| Capacity(T) | 100 | 60 |
| Min open(mm) | 381 | 140 |
| Pulling depth of min open(mm) | 1066 | 790 |
| Max open(mm) | 1219 | 1000 |
| Depth of max open(mm) | 863 | 850 |
| Overall length(mm) | 3015 | 2885 |
|
Regulation of puller center height(mm) |
380~915 | 380·815 |
| Cylinder stroke (mm) | 250 | 250 |
| Source of power（single phase） | 220V/380V | 220V/380V |
| L(mm) | 3015 | 2885 |
| H(mm) | 1276 | 1276 |
| W(mm) | 930 | 930 |
Two jaws design easy to operate.
With safety lock unit.
Roller cart makes it available to change workplace.
