MP series electric pump adopts integrated way: by the oil pump, control valve, fuel tanks, pneumatic motor, cooler, such as instrument of a kind of independent complete hydraulic device, has small volume, light weight, simple structure, convenient operation, high working pressure, etc. The pump is high and low pressure oil pump, can obtain the larger output oil. When high pressure, the low pressure pump is automatically returned to oil by unloading overflow valve and can reduce the power consumption, and (A) the oil pressure can be adjusted by 70~ 700Bar.
CONTACT US
double-speed designed , infinitely variable pressure adjustment between 0~700bar
modularity product , supply more than 200 kinds electric pump
MP Series Selection Chart：
|
Tank Capacity |
Power (KW) |
Rated Pressure (bar) |
Output Flow (L/min) |
Source of Power V/Hz |
Maxing Operating Pressure (bar) |
||
| First stage | Second stage | First stage | Second stage | ||||
| 4L | 1.0 |
65 |
700 |
4 | 0.6 |
200V,50Hz& 380V,50Hz& |
700 |
|
8L and above |
1.1 | 5.5/7.2 | 0.8 | ||||
Schematic iagram of valve group module：
Type A：Manual Valve Type B：Manual Valve Type C：Solenoid Valve Type D：Solenoid Valve Type H：Solenoid Valve
(double-acting) (single-acting) (single-acting) (single-acting) (double-acting)
Universal valve block of MP series pump
